C1111-4PWN Cisco 1100 Series ISR with Dual GE WAN

C1111-4PWN Technical Specifications

Cisco 1100 Series Integrated Services Router

Description
The ISR 1100 features a 4-port Dual GE WAN Router equipped with 802.11ac -N WiFi capabilities.
Physical Properties
Dimensions (H x W x D): Non-LTE models measure H x W x D = 1.75 x 12.7 x 9.03 in. (42 x 323 x 230mm) including rubber feet.
Weight: 5.5 lbs. (2.5 kg) maximum without modules.
AC Input Power
Input Voltage: Universal 100 to 240 VAC.
Frequency: 50-60 Hz.
Input Current: PoE not enabled: 0.82A maximum; PoE enabled: 1.55A maximum.
Surge Current: 90 A peak and under 8 Arms per half cycle.
Ports
Includes a Micro USB port, one RJ-45 console port, USB 3.0 Type A host port for USB flash memory, and two GE ports configured as one combo port (10/100/1000 RJ-45 or SFP) and one dedicated RJ-45 port.
Wireless VLANs
Supports 32 VLANs, both encrypted and non-encrypted. Wireless specifications include 2×2 .11ac Wave 2 with a maximum of 4GB DRAM and flash.
Inline PoE
Offers 4 ports for -8P PIDs and 2 ports for -4P PIDs, compliant with 802.3af and 802.3at PoE+.
Acoustic: Fanless design ensures quiet operation.
