UCS-SP-C240M4-B-S1 Cisco UCS C240 M4SX Rack Server

UCS-SP-C240M4-B-S1 Technical Specifications

Cisco UCS SmartPlay Select C240 M4SX Standard

Bay Provided
Form Factor: 2.5″ SFF
Free Qty: 16
Total Qty: 24 Bays
Cabinet
Chassis Built-in Devices: Backplane
Cable
Connectivity Type: Keyboard / mouse / video cable
Cache Memory
Installed Size: 50 MB
Per Processor Size: 25 MB
Type: L3 cache
Chassis
Form Factor: Rack-mountable
Hot-Swap Bays Qty: 24
Server Storage Bays: Hot swap
Server Swappable Drive Interface: SATA/SAS
Dimensions & Weight
Depth: 29.1 in
Height: 3.4 in
Width: 17.6 in
Environmental Parameters
Humidity Range Operating: 10 – 90% (non-condensing)
Max Operating Temperature: 95 °F
Min Operating Temperature: 41 °F
Expansion Slots
Type: CPU, DIMM 288-pin, PCIe x16, PCIe x8, SD card
Processor
Clock Speed: 2.2 GHz
Installed Qty: 2
Processor Number: E5-2630V4
RAM
Installed Size: 128 GB
Max Supported Size: 768 GB
Technology: DDR4 SDRAM
Power Device
Power Provided: 1400 Watt
Power Redundancy: Yes
Type: Power supply – hot-plug
Networking
Data Link Protocol: 10Gb FCoE, Ethernet
Ethernet Ports: 2 x Gigabit Ethernet, 2 x SFP+
